# Check Grafana version:
docker exec grafana grafana-cli --version

# Verify you have 30+ days of Prometheus data:
curl -s 'http://localhost:9090/api/v1/query?query=count(up)' | \
  jq '.data.result | length'

# Check if application metrics exist (needed for SLOs):
curl -s 'http://localhost:9090/api/v1/label/__name__/values' | \
  jq '.data | map(select(startswith("http_requests")))'
# Should show http_requests_total or similar application metrics

# Current Grafana database backend:
docker exec grafana grafana-cli admin reset-admin-password --help 2>&1 | \
  grep -i database || echo 'Check grafana.ini for database section'

# docker-compose.ha.yml — Deploy on EACH Grafana node
# Both nodes share the same PostgreSQL and Redis

version: '3.8'

services:
  grafana:
    image: grafana/grafana-oss:latest
    container_name: grafana_node
    restart: unless-stopped
    ports:
      - "3000:3000"
    environment:
      # Database — use PostgreSQL instead of SQLite:
      GF_DATABASE_TYPE: postgres
      GF_DATABASE_HOST: pg.internal.yourdomain.com:5432
      GF_DATABASE_NAME: grafana
      GF_DATABASE_USER: grafana
      GF_DATABASE_PASSWORD: ${PG_PASSWORD}
      GF_DATABASE_SSL_MODE: require

      # Session store — use Redis for cross-node sessions:
      GF_SESSION_PROVIDER: redis
      GF_SESSION_PROVIDER_CONFIG: addr=redis.internal.yourdomain.com:6379,password=${REDIS_PASSWORD},db=0

      # Security:
      GF_SECURITY_ADMIN_USER: admin
      GF_SECURITY_ADMIN_PASSWORD: ${GRAFANA_ADMIN_PASSWORD}
      GF_SECURITY_SECRET_KEY: ${GRAFANA_SECRET_KEY}
      # Must be identical on all nodes — used for cookie signing

      # Server config:
      GF_SERVER_ROOT_URL: https://grafana.yourdomain.com
      GF_SERVER_DOMAIN: grafana.yourdomain.com

      # HA mode — enables distributed alerting:
      GF_UNIFIED_ALERTING_HA_PEERS: grafana-node1.internal:9094,grafana-node2.internal:9094
      GF_UNIFIED_ALERTING_HA_LISTEN_ADDRESS: :9094
      GF_UNIFIED_ALERTING_HA_ADVERTISE_ADDRESS: ${NODE_IP}:9094

      # Disable user signup (manage users centrally):
      GF_USERS_ALLOW_SIGN_UP: "false"

      # SMTP for alert notifications:
      GF_SMTP_ENABLED: "true"
      GF_SMTP_HOST: ${SMTP_HOST}:587
      GF_SMTP_USER: ${SMTP_USER}
      GF_SMTP_PASSWORD: ${SMTP_PASSWORD}
      GF_SMTP_FROM_ADDRESS: [email protected]

    volumes:
      - grafana_data:/var/lib/grafana
      - ./grafana/provisioning:/etc/grafana/provisioning:ro
    healthcheck:
      test: ["CMD-SHELL", "curl -f http://localhost:3000/api/health || exit 1"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 60s

volumes:
  grafana_data:

# First: migrate existing SQLite dashboards to PostgreSQL
# This is a one-time operation before enabling HA

# Export all dashboards from current SQLite Grafana:
curl -s http://admin:pass@localhost:3000/api/search?type=dash-db | \
  jq -r '.[].uid' | while read uid; do
    curl -s "http://admin:pass@localhost:3000/api/dashboards/uid/$uid" | \
      jq .dashboard > "backups/dashboard_${uid}.json"
    echo "Exported: $uid"
done

# Export data sources:
curl -s http://admin:pass@localhost:3000/api/datasources | \
  jq '.' > backups/datasources.json

# Start new HA Grafana pointing at PostgreSQL:
docker compose -f docker-compose.ha.yml up -d

# Wait for first-time database migration to complete:
docker compose logs -f grafana_node | grep -E '(migration|ready|started)'

# Import dashboards into the new HA instance:
jq -c '.[]' backups/datasources.json | while read ds; do
    curl -s -X POST http://admin:newpass@localhost:3000/api/datasources \
      -H 'Content-Type: application/json' \
      -d "$ds" | jq .message
done

# Import dashboards:
for f in backups/dashboard_*.json; do
    uid=$(basename $f .json | sed 's/dashboard_//')
    curl -s -X POST http://admin:newpass@localhost:3000/api/dashboards/import \
      -H 'Content-Type: application/json' \
      -d "{\"dashboard\": $(cat $f), \"overwrite\": true}" | jq .status
done

# Load balancer for Grafana HA:
# /etc/nginx/sites-available/grafana-ha
upstream grafana_nodes {
    ip_hash;  # Sticky sessions for SSO compatibility
    server grafana-node1.internal:3000 max_fails=3 fail_timeout=30s;
    server grafana-node2.internal:3000 max_fails=3 fail_timeout=30s;
}

server {
    listen 443 ssl http2;
    server_name grafana.yourdomain.com;
    ssl_certificate /etc/letsencrypt/live/grafana.yourdomain.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/grafana.yourdomain.com/privkey.pem;

    location / {
        proxy_pass http://grafana_nodes;
        proxy_http_version 1.1;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        # WebSocket for live dashboard updates:
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
    }
}

# Add business event counters to your application code
# These are exposed via the /metrics endpoint alongside technical metrics

# Node.js example with prom-client:
const client = require('prom-client');

// Business event counters:
const ordersCreated = new client.Counter({
  name: 'business_orders_created_total',
  help: 'Total orders created',
  labelNames: ['status', 'payment_method', 'region']
});

const revenueProcessed = new client.Counter({
  name: 'business_revenue_processed_cents_total',
  help: 'Total revenue processed in cents',
  labelNames: ['currency', 'payment_method']
});

const activeSubscriptions = new client.Gauge({
  name: 'business_active_subscriptions',
  help: 'Currently active paid subscriptions',
  labelNames: ['plan_type']
});

const userSignups = new client.Counter({
  name: 'business_user_signups_total',
  help: 'Total user registrations',
  labelNames: ['source', 'plan']
});

// Instrument your business logic:
app.post('/orders', async (req, res) => {
  try {
    const order = await createOrder(req.body);
    ordersCreated.inc({ status: 'created', payment_method: order.payment_method, region: order.region });
    revenueProcessed.inc({ currency: order.currency, payment_method: order.payment_method }, order.total_cents);
    res.json(order);
  } catch (err) {
    ordersCreated.inc({ status: 'failed', payment_method: req.body.payment_method, region: req.body.region });
    throw err;
  }
});

// Python example with prometheus_client:
from prometheus_client import Counter, Gauge, Histogram

orders_created = Counter(
    'business_orders_created_total',
    'Total orders created',
    ['status', 'payment_method']
)

checkout_duration = Histogram(
    'business_checkout_duration_seconds',
    'Time spent in checkout flow',
    buckets=[0.5, 1.0, 2.5, 5.0, 10.0, 30.0]
)

# PromQL queries for business metrics dashboards:
# Create these as panels in a "Business Overview" dashboard

# Current order rate (orders per minute, last 5 minutes):
rate(business_orders_created_total{status="created"}[5m]) * 60

# Order failure rate (% of orders failing):
rate(business_orders_created_total{status="failed"}[5m])
  /
  rate(business_orders_created_total[5m]) * 100

# Revenue rate (USD/hour):
rate(business_revenue_processed_cents_total[1h]) * 3600 / 100

# Active subscriptions by plan:
business_active_subscriptions

# User signup rate (last 24h):
sum(increase(business_user_signups_total[24h]))

# Revenue by payment method (last 24h):
sum by (payment_method) (increase(business_revenue_processed_cents_total[24h])) / 100

# Order success rate trend (7-day rolling):
sum(rate(business_orders_created_total{status="created"}[7d]))
  /
  sum(rate(business_orders_created_total[7d])) * 100

# Checkout abandonment (started but not completed):
1 - (
  rate(business_orders_created_total{status="created"}[1h])
  /
  rate(business_checkout_started_total[1h])
)

# Alert: Revenue processing has stopped
# Alert if no revenue has been processed in 30 minutes during business hours:
sum(increase(business_revenue_processed_cents_total[30m])) == 0
  and on() (hour() >= 8 and hour() <= 22)  # Business hours filter

# Add Prometheus recording rules to pre-compute SLO metrics
# Recording rules make SLO queries fast even over long time ranges
# prometheus/rules/slo-rules.yml

groups:
  - name: slo_computations
    interval: 30s
    rules:

      # Payment API — Availability SLO (99.9%)
      # Good requests = any HTTP response that isn't 5xx
      - record: slo:payment_api:request_success_rate_5m
        expr: |
          sum(rate(http_requests_total{service="payment-api",status!~"5.."}[5m]))
          /
          sum(rate(http_requests_total{service="payment-api"}[5m]))

      # Payment API — Latency SLO (P95 < 500ms)
      - record: slo:payment_api:p95_latency_5m
        expr: |
          histogram_quantile(0.95,
            sum(rate(http_request_duration_seconds_bucket{service="payment-api"}[5m]))
            by (le)
          )

      # Error budget consumption — rolling 30 days
      # Error budget = 1 - SLO target = 1 - 0.999 = 0.001
      # Budget consumed = (1 - actual_availability) / error_budget
      - record: slo:payment_api:error_budget_consumed_30d
        expr: |
          (
            1 - (
              sum(increase(http_requests_total{service="payment-api",status!~"5.."}[30d]))
              /
              sum(increase(http_requests_total{service="payment-api"}[30d]))
            )
          )
          / 0.001  # Error budget: 0.1% of requests can fail

      # Checkout service — Multi-window availability (used for burn rate alerts)
      - record: slo:checkout:availability_1h
        expr: |
          sum(rate(http_requests_total{service="checkout",status!~"5.."}[1h]))
          / sum(rate(http_requests_total{service="checkout"}[1h]))

      - record: slo:checkout:availability_6h
        expr: |
          sum(rate(http_requests_total{service="checkout",status!~"5.."}[6h]))
          / sum(rate(http_requests_total{service="checkout"}[6h]))

      - record: slo:checkout:availability_3d
        expr: |
          sum(rate(http_requests_total{service="checkout",status!~"5.."}[3d]))
          / sum(rate(http_requests_total{service="checkout"}[3d]))

      - record: slo:checkout:availability_30d
        expr: |
          sum(rate(http_requests_total{service="checkout",status!~"5.."}[30d]))
          / sum(rate(http_requests_total{service="checkout"}[30d]))

# SLO Dashboard panels — create a dedicated "SLO Status" dashboard
# All queries reference the recording rules for fast rendering

# Panel 1: Error Budget Remaining (Gauge)
# Shows how much of your monthly error budget is left
# Expression:
(1 - slo:payment_api:error_budget_consumed_30d) * 100
# Threshold colors:
# Green: >50% remaining
# Yellow: 25-50% remaining
# Red: <25% remaining (burning budget fast)

# Panel 2: Current Availability (Stat)
# Shows real-time availability vs SLO target
# Expression:
slo:payment_api:request_success_rate_5m * 100
# With threshold at 99.9 (the SLO target)

# Panel 3: 30-Day Availability Timeline (Time series)
# Shows availability trend over the month
# Expression:
sum_over_time(slo:payment_api:request_success_rate_5m[30d:5m]) / count_over_time(slo:payment_api:request_success_rate_5m[30d:5m]) * 100

# Panel 4: Burn Rate (burn rate > 1 = burning budget faster than monthly budget)
# If burn rate > 14.4: you'll exhaust your 30-day budget in 50 hours
(1 - slo:payment_api:request_success_rate_5m) / (1 - 0.999)

# Multi-window Burn Rate Alert Rules:
# These catch both fast burns (sudden outage) and slow burns (degraded service)
# In Grafana Alerting → Alert Rules:

# Fast burn alert (page now — exhausts budget in 1 hour):
# 1h burn rate > 14.4 AND 5m burn rate > 14.4
(
  (1 - slo:checkout:availability_1h) / (1 - 0.999) > 14.4
)
and
(
  (1 - slo:checkout:availability_6h) / (1 - 0.999) > 14.4
)

# Slow burn alert (page in business hours — will exhaust budget in 6 days):
# 6h burn rate > 6 AND 3d burn rate > 6
(
  (1 - slo:checkout:availability_6h) / (1 - 0.999) > 6
)
and
(
  (1 - slo:checkout:availability_3d) / (1 - 0.999) > 6
)

# Add Grafana OnCall to your monitoring stack:
# docker-compose.yml additions:

  oncall-engine:
    image: grafana/oncall:latest
    container_name: oncall_engine
    restart: unless-stopped
    command: uwsgi --ini uwsgi.ini
    environment:
      DATABASE_TYPE: postgresql
      DATABASE_HOST: postgres
      DATABASE_PORT: 5432
      DATABASE_NAME: oncall
      DATABASE_USER: oncall
      DATABASE_PASSWORD: ${ONCALL_DB_PASSWORD}
      BROKER_TYPE: redis
      REDIS_URI: redis://:${REDIS_PASSWORD}@redis:6379/3
      SECRET_KEY: ${ONCALL_SECRET_KEY}
      GRAFANA_API_URL: http://grafana:3000
      GRAFANA_ONCALL_DJANGO_SETTINGS_MODULE: settings.prod_without_db_initialization
      # Telegram/Slack notifications:
      TELEGRAM_TOKEN: ${TELEGRAM_BOT_TOKEN:-}
      SLACK_CLIENT_ID: ${SLACK_CLIENT_ID:-}
      SLACK_CLIENT_SECRET: ${SLACK_CLIENT_SECRET:-}
    depends_on:
      - postgres
      - redis
    networks:
      - monitoring

  oncall-celery:
    image: grafana/oncall:latest
    container_name: oncall_celery
    restart: unless-stopped
    command: celery -A engine worker -l info -c 2
    environment:
      # Same as engine
      DATABASE_TYPE: postgresql
      DATABASE_HOST: postgres
      DATABASE_PORT: 5432
      DATABASE_NAME: oncall
      DATABASE_USER: oncall
      DATABASE_PASSWORD: ${ONCALL_DB_PASSWORD}
      BROKER_TYPE: redis
      REDIS_URI: redis://:${REDIS_PASSWORD}@redis:6379/3
      SECRET_KEY: ${ONCALL_SECRET_KEY}
    depends_on:
      - oncall-engine
    networks:
      - monitoring

# Create OnCall database:
docker exec postgres psql -U postgres -c "CREATE DATABASE oncall OWNER oncall;"

docker compose up -d oncall-engine oncall-celery

# Install OnCall plugin in Grafana:
# Grafana → Administration → Plugins → search "Grafana OnCall" → Install
# Or via CLI:
docker exec grafana grafana-cli plugins install grafana-oncall-app
docker compose restart grafana

# Configure OnCall via Grafana OnCall plugin UI:
# Grafana → OnCall → Users → Connect notification channels
# Each team member connects: Telegram, Slack, Email, Phone (via webhook)

# Example on-call schedule setup via OnCall API:
ONCALL_URL="http://localhost:8080"  # OnCall engine
ONCALL_TOKEN="your-oncall-api-token"

# Create an on-call schedule (weekly rotation):
curl -X POST "${ONCALL_URL}/api/v1/schedules/" \
  -H "Authorization: ${ONCALL_TOKEN}" \
  -H 'Content-Type: application/json' \
  -d '{
    "name": "Backend On-Call",
    "type": "web",
    "time_zone": "UTC",
    "shifts": [{
      "name": "Week 1",
      "type": "recurrent_event",
      "duration": 604800,
      "rotation_start": "2026-04-06T00:00:00Z",
      "frequency": "weekly",
      "interval": 1,
      "by_day": ["MO"],
      "users": ["USER_ID_ALICE", "USER_ID_BOB", "USER_ID_CAROL"]
    }]
  }' | jq .id

# Create escalation policy:
curl -X POST "${ONCALL_URL}/api/v1/escalation_policies/" \
  -H "Authorization: ${ONCALL_TOKEN}" \
  -H 'Content-Type: application/json' \
  -d '{
    "name": "Backend Escalation",
    "steps": [
      {
        "type": "notify_on_call_from_schedule",
        "notify_on_call_from_schedule": "SCHEDULE_ID",
        "wait_delay": "00:00:00"  # Immediately notify on-call engineer
      },
      {
        "type": "wait",
        "wait_delay": "00:15:00"  # Wait 15 minutes
      },
      {
        "type": "notify_persons",
        "persons_to_notify": ["MANAGER_USER_ID"],  # Escalate to manager
        "wait_delay": "00:00:00"
      }
    ]
  }' | jq .id

# Connect Grafana alerts to OnCall:
# Grafana → Alerting → Contact Points → Add contact point
# Type: Grafana OnCall
# Select: your escalation policy
# Now Grafana alerts automatically page on-call through OnCall

# Provision dashboards via YAML config — version-controlled and reproducible
# grafana/provisioning/dashboards/default.yaml

cat > grafana/provisioning/dashboards/default.yaml << 'EOF'
apiVersion: 1

providers:
  - name: 'default'
    orgId: 1
    folder: 'Production'
    folderUid: 'production'
    type: file
    disableDeletion: true      # Prevent UI deletions of provisioned dashboards
    editable: false             # Read-only in UI (editable = false)
    updateIntervalSeconds: 10
    allowUiUpdates: false
    options:
      path: /etc/grafana/provisioning/dashboards
      foldersFromFilesStructure: true  # Subdirectories become folders

  - name: 'slos'
    orgId: 1
    folder: 'SLOs'
    type: file
    disableDeletion: true
    options:
      path: /etc/grafana/provisioning/dashboards/slos
EOF

# Create a parameterized dashboard JSON and commit to Git:
# Every team member can view dashboards without Grafana access
# Changes go through pull request review

# Export a dashboard for version control:
curl -s http://admin:pass@localhost:3000/api/dashboards/uid/payment-overview | \
  jq '{dashboard: .dashboard, overwrite: true}' > \
  grafana/provisioning/dashboards/payment-overview.json

# Mount provisioning directory in Grafana:
# In docker-compose.yml:
# volumes:
#   - ./grafana/provisioning:/etc/grafana/provisioning:ro

# Apply changes (Grafana watches the directory):
docker compose restart grafana
# Or: Grafana auto-reloads provisioned dashboards every 10s

# Symptom: Alert fires on node1, resolved on node2, but node1 still shows firing
# Cause: Alerting HA peer discovery not working

# Check HA peer connectivity:
docker exec grafana_node curl -s http://grafana-node2.internal:9094/
# Should return something — if connection refused, peers can't reach each other

# Verify the HA advertise addresses are correct:
docker exec grafana_node env | grep -i 'HA\|ALERTING'
# GF_UNIFIED_ALERTING_HA_ADVERTISE_ADDRESS should be THIS node's IP, not 0.0.0.0

# Check HA status in Grafana logs:
docker logs grafana_node | grep -iE '(ha|gossip|peer|cluster)'
# Should show: "Starting ha scheduler" and "joining cluster"

# Test by checking both nodes show the same alert state:
curl -s http://grafana-node1.internal:3000/api/alertmanager/grafana/api/v2/alerts | \
  jq 'length'
curl -s http://grafana-node2.internal:3000/api/alertmanager/grafana/api/v2/alerts | \
  jq 'length'
# Should be identical

# If firewall is blocking port 9094 (alerting HA port):
sudo ufw allow 9094/tcp
# From the monitoring network to both Grafana nodes

# NaN in SLO queries usually means the denominator is 0 (no requests in window)

# Debug by querying the raw metric:
curl -s 'http://localhost:9090/api/v1/query?query=sum(rate(http_requests_total{service="payment-api"}[5m]))' | jq .

# If the result is empty: service label doesn't match your actual metric labels
# Check actual label names:
curl -s 'http://localhost:9090/api/v1/label/service/values' | jq .data

# If service label doesn't exist, check what labels your metrics have:
curl -s 'http://localhost:9090/api/v1/query?query=http_requests_total[5m]' | \
  jq '.data.result[0].metric'
# Shows all labels on the metric — use the correct label name in your SLO query

# Prevent division by zero with or vector(0):
(
  sum(rate(http_requests_total{service="payment-api",status!~"5.."}[5m]))
  or vector(0)
)
/
(
  sum(rate(http_requests_total{service="payment-api"}[5m]))
  or vector(1)  # Default to 100% if no traffic
)

# If recording rules aren't updating:
curl -s http://localhost:9090/api/v1/rules | \
  jq '.data.groups[] | select(.name=="slo_computations") | .evaluationTime'
# Should be < 30s (our evaluation interval)

# Check OnCall engine logs:
docker logs oncall_engine --tail 50 | grep -iE '(error|notification|telegram|slack)'

# Check Celery worker is processing tasks:
docker logs oncall_celery --tail 20 | grep -iE '(task|error|received)'

# Verify the integration is connected to Grafana:
curl -s ${ONCALL_URL}/api/v1/integrations/ \
  -H "Authorization: ${ONCALL_TOKEN}" | jq '[.[] | {name: .name, type: .type}]'

# Test notification delivery:
curl -X POST ${ONCALL_URL}/api/v1/send_demo_alert/ \
  -H "Authorization: ${ONCALL_TOKEN}" \
  -d '{"integration_id": "YOUR_INTEGRATION_ID"}'
# Should trigger a test notification through your notification channels

# Check user notification preferences are set:
curl -s ${ONCALL_URL}/api/v1/users/me/ \
  -H "Authorization: ${ONCALL_TOKEN}" | \
  jq '.notification_rules'
# Each user needs at least one notification rule (Telegram, email, etc.)

# If Telegram bot isn't responding:
# Verify the bot token:
curl -s https://api.telegram.org/bot${TELEGRAM_TOKEN}/getMe | jq .ok
# Should return: true
