cd ~/monitoring
docker compose ps

# Verify Grafana is running and has data:
curl -s http://admin:password@localhost:3000/api/health | jq .database
# Should return: "ok"

# Verify Prometheus is scraping successfully:
curl -s 'http://localhost:9090/api/v1/query?query=up' | \
  jq '.data.result | length'
# Should return your number of targets

# Check available disk space:
df -h /
# Need at least 20GB free before adding Loki

# Add Loki and Promtail to your existing docker-compose.yml:

  loki:
    image: grafana/loki:latest
    container_name: loki
    restart: unless-stopped
    ports:
      - "3100:3100"
    volumes:
      - loki_data:/loki
      - ./loki/loki-config.yml:/etc/loki/local-config.yaml:ro
    command: -config.file=/etc/loki/local-config.yaml
    networks:
      - monitoring
    healthcheck:
      test: ["CMD-SHELL", "wget --quiet --tries=1 --spider http://localhost:3100/ready || exit 1"]
      interval: 30s
      timeout: 10s
      retries: 5

  promtail:
    image: grafana/promtail:latest
    container_name: promtail
    restart: unless-stopped
    volumes:
      # Tail Docker container logs:
      - /var/log:/var/log:ro
      - /var/lib/docker/containers:/var/lib/docker/containers:ro
      - /run/docker.sock:/run/docker.sock:ro
      - ./loki/promtail-config.yml:/etc/promtail/config.yml:ro
    command: -config.file=/etc/promtail/config.yml
    networks:
      - monitoring
    user: root  # Required to read Docker socket and container logs

volumes:
  loki_data:
    driver: local

mkdir -p loki

# loki/loki-config.yml
cat > loki/loki-config.yml << 'EOF'
auth_enabled: false

server:
  http_listen_port: 3100
  grpc_listen_port: 9096

common:
  path_prefix: /loki
  storage:
    filesystem:
      chunks_directory: /loki/chunks
      rules_directory: /loki/rules
  replication_factor: 1
  ring:
    instance_addr: 127.0.0.1
    kvstore:
      store: inmemory

schema_config:
  configs:
    - from: 2024-01-01
      store: tsdb
      object_store: filesystem
      schema: v13
      index:
        prefix: index_
        period: 24h

ruler:
  alertmanager_url: http://alertmanager:9093

limits_config:
  # Retain logs for 30 days:
  retention_period: 720h
  # Reject individual log lines larger than 1MB:
  max_line_size: 1MB
  # Per-stream ingestion rate limits:
  ingestion_rate_mb: 16
  ingestion_burst_size_mb: 32

compactor:
  working_directory: /loki/compactor
  retention_enabled: true
EOF

# loki/promtail-config.yml
cat > loki/promtail-config.yml << 'EOF'
server:
  http_listen_port: 9080
  grpc_listen_port: 0

positions:
  filename: /tmp/positions.yaml

clients:
  - url: http://loki:3100/loki/api/v1/push

scrape_configs:
  # Scrape all Docker container logs automatically:
  - job_name: docker-containers
    docker_sd_configs:
      - host: unix:///run/docker.sock
        refresh_interval: 5s
    relabel_configs:
      # Use the container name as the app label:
      - source_labels: [__meta_docker_container_name]
        regex: /(.*)
        target_label: app
      # Preserve the container ID:
      - source_labels: [__meta_docker_container_id]
        target_label: container_id
      # Add environment label from container label:
      - source_labels: [__meta_docker_container_label_env]
        target_label: env
    pipeline_stages:
      # Parse JSON logs (many apps log structured JSON):
      - json:
          expressions:
            level: level
            message: message
            timestamp: time
      # Extract log level for filtering:
      - labels:
          level:
      # Drop debug logs to reduce storage cost:
      - drop:
          source: level
          value: debug

  # Also tail system logs:
  - job_name: system
    static_configs:
      - targets:
          - localhost
        labels:
          job: syslog
          __path__: /var/log/syslog
    pipeline_stages:
      - regex:
          expression: '(?P\S+\s+\S+\s+\S+) (?P\S+) (?P\S+): (?P.*)'
      - labels:
          service:
EOF

docker compose up -d loki promtail
docker compose logs -f loki promtail | head -30

# Add Loki as a data source in Grafana:
# Connections → Data Sources → Add data source → Loki
# URL: http://loki:3100
# Save & test

# Essential LogQL queries for the Explore view:

# All logs from a specific container in the last hour:
{app="nginx"}

# Error logs across ALL containers:
{app=~".+"} |= "error" | json | level="error"

# Logs from your API with parsing:
{app="api"} | json | status >= 500

# Count errors per minute over the last hour:
sum(rate({app=~".+"} |= "error" [1m])) by (app)

# Find logs around a specific timestamp (useful with traces):
{app="payment-api"}
  | json
  | line_format "{{.timestamp}} {{.level}} {{.message}}"

# Find all logs for a specific request trace ID:
{app=~".+"} |= "trace_id=abc123"

# Log volume rate per service (for volume dashboard):
sum by (app) (rate({app=~".+"}[5m]))

# Verify Loki is receiving logs:
curl -s 'http://localhost:3100/loki/api/v1/labels' | jq .data
# Should list: app, container_id, env, level, etc.

# Add Tempo to docker-compose.yml:

  tempo:
    image: grafana/tempo:latest
    container_name: tempo
    restart: unless-stopped
    ports:
      - "3200:3200"    # Tempo HTTP API
      - "4317:4317"    # OTLP gRPC (OpenTelemetry)
      - "4318:4318"    # OTLP HTTP (OpenTelemetry)
      - "9411:9411"    # Zipkin compatibility
      - "14268:14268"  # Jaeger HTTP thrift
    volumes:
      - tempo_data:/var/tempo
      - ./tempo/tempo-config.yml:/etc/tempo/tempo.yaml:ro
    command: -config.file=/etc/tempo/tempo.yaml
    networks:
      - monitoring

volumes:
  tempo_data:
    driver: local

---
# tempo/tempo-config.yml
mkdir -p tempo

cat > tempo/tempo-config.yml << 'EOF'
server:
  http_listen_port: 3200

distributor:
  receivers:
    otlp:
      protocols:
        grpc:
          endpoint: 0.0.0.0:4317
        http:
          endpoint: 0.0.0.0:4318
    jaeger:
      protocols:
        thrift_http:
          endpoint: 0.0.0.0:14268
    zipkin:
      endpoint: 0.0.0.0:9411

ingester:
  max_block_duration: 5m

compactor:
  compaction:
    block_retention: 336h  # 14 days of traces

storage:
  trace:
    backend: local
    local:
      path: /var/tempo/traces
    wal:
      path: /var/tempo/wal

metrics_generator:
  # Generate RED metrics (Rate, Errors, Duration) from traces:
  registry:
    external_labels:
      source: tempo
  storage:
    path: /var/tempo/generator/wal
    remote_write:
      - url: http://prometheus:9090/api/v1/write
        send_exemplars: true

overrides:
  defaults:
    metrics_generator:
      processors: [service-graphs, span-metrics]
      generate_native_histograms: both
EOF

docker compose up -d tempo
docker compose logs tempo --tail 20

# Verify Tempo is accepting traces:
curl -s http://localhost:3200/ready
# Should return: ready

# Instrument a Node.js application with OpenTelemetry
# This auto-instruments HTTP, Express, database drivers, etc.

npm install @opentelemetry/sdk-node \
  @opentelemetry/auto-instrumentations-node \
  @opentelemetry/exporter-trace-otlp-http

# Create tracing.js — load BEFORE your application code:
cat > tracing.js << 'EOF'
const { NodeSDK } = require('@opentelemetry/sdk-node');
const { getNodeAutoInstrumentations } = require('@opentelemetry/auto-instrumentations-node');
const { OTLPTraceExporter } = require('@opentelemetry/exporter-trace-otlp-http');
const { Resource } = require('@opentelemetry/resources');
const { SEMRESATTRS_SERVICE_NAME, SEMRESATTRS_SERVICE_VERSION } = require('@opentelemetry/semantic-conventions');

const sdk = new NodeSDK({
  resource: new Resource({
    [SEMRESATTRS_SERVICE_NAME]: process.env.SERVICE_NAME || 'my-api',
    [SEMRESATTRS_SERVICE_VERSION]: process.env.SERVICE_VERSION || '1.0.0',
  }),
  traceExporter: new OTLPTraceExporter({
    // Send traces to Tempo:
    url: process.env.OTEL_EXPORTER_OTLP_ENDPOINT || 'http://tempo:4318/v1/traces',
  }),
  instrumentations: [getNodeAutoInstrumentations({
    '@opentelemetry/instrumentation-http': { enabled: true },
    '@opentelemetry/instrumentation-express': { enabled: true },
    '@opentelemetry/instrumentation-pg': { enabled: true },
    '@opentelemetry/instrumentation-redis': { enabled: true },
  })],
});

sdk.start();
process.on('SIGTERM', () => sdk.shutdown());
EOF

# Start your app with tracing:
node -r ./tracing.js server.js
# Or in package.json:
# "start": "node -r ./tracing.js server.js"

# Add to your Dockerfile:
# ENV NODE_OPTIONS="--require ./tracing.js"

# For Python applications:
pip install opentelemetry-distro opentelemetry-exporter-otlp
opentelemetry-bootstrap -a install
opentelemetry-instrument \
  --service_name my-python-api \
  --traces_exporter otlp \
  --exporter_otlp_endpoint http://tempo:4318/v1/traces \
  python app.py

# Add trace context to your application logs so you can
# jump from a trace span directly to the logs for that request

# Node.js: inject trace ID into log output:
const { trace, context } = require('@opentelemetry/api');

// Custom logger that includes trace context:
function log(level, message, extra = {}) {
    const span = trace.getActiveSpan();
    const traceContext = span ? {
        trace_id: span.spanContext().traceId,
        span_id: span.spanContext().spanId,
    } : {};

    console.log(JSON.stringify({
        level,
        message,
        timestamp: new Date().toISOString(),
        service: process.env.SERVICE_NAME,
        ...traceContext,
        ...extra
    }));
}

// Usage:
app.get('/api/orders/:id', async (req, res) => {
    log('info', 'Processing order request', { order_id: req.params.id });
    // The log now contains trace_id that matches the Tempo trace
    // In Grafana, you can click a trace span and jump directly
    // to the correlated logs in Loki
});

# Configure Grafana to link Loki logs to Tempo traces:
# Loki Data Source → Derived Fields:
# Name: TraceID
# Regex: trace_id=(\w+)
# URL: http://tempo:3200/api/traces/$${__value.raw}
# Internal link: Tempo data source

# Now in the Explore view:
# When you see a log line with a trace_id,
# a "Tempo" link appears — click it to jump to the full trace

# Add Mimir to docker-compose.yml (single-binary mode for self-hosted):

  mimir:
    image: grafana/mimir:latest
    container_name: mimir
    restart: unless-stopped
    ports:
      - "9009:9009"  # Mimir HTTP API
    volumes:
      - mimir_data:/data
      - ./mimir/mimir-config.yml:/etc/mimir/mimir.yaml:ro
    command: --config.file=/etc/mimir/mimir.yaml
    networks:
      - monitoring

volumes:
  mimir_data:
    driver: local

---
# mimir/mimir-config.yml
mkdir -p mimir

cat > mimir/mimir-config.yml << 'EOF'
# Single-binary mode — simple, no clustering
target: all,alertmanager

server:
  http_listen_port: 9009
  grpc_listen_port: 9095
  log_level: info

mimir_config:
  blocks_retention_period: 8760h  # 365 days of metrics

blocks_storage:
  backend: filesystem
  filesystem:
    dir: /data/blocks
  tsdb:
    dir: /data/tsdb

compactor:
  data_dir: /data/compactor

distributor:
  ring:
    instance_addr: 127.0.0.1
    kvstore:
      store: memberlist

ingester:
  ring:
    instance_addr: 127.0.0.1
    kvstore:
      store: memberlist
    replication_factor: 1

ruler_storage:
  backend: filesystem
  filesystem:
    dir: /data/rules

alertmanager_storage:
  backend: filesystem
  filesystem:
    dir: /data/alertmanager

memberlist:
  bind_port: 7946
  join_members: []
EOF

# Configure Prometheus to remote_write to Mimir:
# Add to prometheus/prometheus.yml:
cat >> prometheus/prometheus.yml << 'EOF'

remote_write:
  - url: http://mimir:9009/api/v1/push
    send_exemplars: true  # Send exemplars (links from metrics to traces)
EOF

docker compose up -d mimir
docker compose restart prometheus  # Pick up new remote_write config

# Verify Mimir is receiving metrics:
curl -s http://localhost:9009/ready
# Should return: ready

# Add Mimir as a Prometheus-compatible data source in Grafana:
# Data Sources → Add → Prometheus
# URL: http://mimir:9009/prometheus
# Name: Mimir (Long-term)
# Now you can query metrics going back 12 months in Grafana

# Grafana Unified Alerting rules via API
# (Configure in Grafana UI: Alerting → Alert Rules → New rule)

# Rule 1: High error rate with log context
# This alert fires when error rate > 5% AND includes a link to relevant logs

# Alert rule YAML (for Grafana-managed alerts):
cat << 'EOF'
apiVersion: 1
groups:
  - name: Application Alerts
    folder: Production
    interval: 1m
    rules:
      # High API error rate:
      - uid: api-error-rate
        title: High API Error Rate
        condition: C
        data:
          - refId: A
            queryType: range
            relativeTimeRange:
              from: 300
              to: 0
            datasourceUid: prometheus-uid
            model:
              expr: >
                sum(rate(http_requests_total{status=~"5.."}[5m])) by (service)
                /
                sum(rate(http_requests_total[5m])) by (service)
                * 100
          - refId: B
            queryType: reduce
            relativeTimeRange:
              from: 300
              to: 0
            datasourceUid: __expr__
            model:
              type: reduce
              conditions:
                - evaluator:
                    type: gt
                    params: [5.0]  # Alert if > 5% error rate
                  reducer: {type: max}
                  query: {params: [A]}
        noDataState: NoData
        execErrState: Error
        for: 5m
        annotations:
          summary: "High error rate on {{ $labels.service }}"
          description: "Error rate is {{ $values.A }}% (threshold: 5%)"
          # Link to Loki logs for this service at the time of alert:
          runbook: "https://wiki.yourdomain.com/runbooks/{{ $labels.service }}"
        labels:
          severity: warning
          team: backend

      # Database slow queries (Loki-based alert):
      - uid: db-slow-queries
        title: Database Slow Queries Detected
        condition: C
        data:
          - refId: A
            queryType: range
            datasourceUid: loki-uid
            model:
              expr: >-
                sum(rate({app="postgresql"} |= "duration" | regexp `duration=(?P\d+)ms` | duration > 1000 [5m]))
        annotations:
          summary: "PostgreSQL slow queries detected"
          description: "Multiple queries taking >1000ms in the last 5 minutes"
EOF

# Apply the rules via Grafana API:
curl -X POST http://admin:password@localhost:3000/api/ruler/grafana/api/v1/rules/Production \
  -H 'Content-Type: application/yaml' \
  --data-binary @alert-rules.yaml

# Add Uptime Kuma metrics to your Prometheus scrape config:
# prometheus/prometheus.yml — add to scrape_configs:
  - job_name: 'uptime-kuma'
    scrape_interval: 30s
    static_configs:
      - targets: ['uptime-kuma:3001']
    metrics_path: /metrics

# Useful correlation dashboard queries:
# When Uptime Kuma shows a service is down AND Grafana shows the error:

# 1. Which service is down right now? (from Uptime Kuma):
monitor_status == 0

# 2. What's the error rate for the same service? (from Prometheus):
rate(http_requests_total{service="$service",status=~"5.."}[5m])

# 3. What do the logs show during the outage? (from Loki):
{app="$service"} | json | level="error"

# Build a unified dashboard that overlays all three:
# - Uptime Kuma availability as status annotations on the timeline
# - Prometheus error rate as the main graph
# - Loki log volume as a bar chart at the bottom
# - When you see a dip in availability, click to expand logs below

# Check Promtail is running and can reach Loki:
docker logs promtail --tail 30 | grep -iE '(error|warn|send|failed)'

# Verify Promtail can read the Docker socket:
docker exec promtail ls -la /run/docker.sock
# Should show the socket file — if permission denied, add user: root to Promtail service

# Check what Promtail is discovering:
curl -s http://localhost:9080/targets | jq '.[] | select(.health != "up")'
# Shows any failing scrape targets

# Verify logs are reaching Loki:
curl -s 'http://localhost:3100/loki/api/v1/labels' | jq .data
# Should show your labels: app, container_id, env, level, etc.
# If empty, Promtail isn't pushing logs

# Check Loki ingestion rate:
curl -s 'http://localhost:3100/metrics' | grep loki_ingester_streams_total

# Common fix: Promtail needs to run as root to read Docker socket:
# In docker-compose.yml under promtail:
# user: root
# security_opt:
#   - no-new-privileges:true

# Test log ingestion manually:
curl -X POST http://localhost:3100/loki/api/v1/push \
  -H 'Content-Type: application/json' \
  -d '{"streams":[{"stream":{"app":"test"},"values":[["'$(date +%s)'000000000","test log entry"]]}]}'
# Then query: {app="test"} in Grafana Explore

# Check Tempo is running:
curl -s http://localhost:3200/ready
# Should return: ready

# Check if traces are being received:
curl -s http://localhost:3200/metrics | grep tempo_distributor_spans_received_total
# Should increment after sending test traces

# Send a test trace directly to Tempo:
curl -X POST http://localhost:4318/v1/traces \
  -H 'Content-Type: application/json' \
  -d '{
    "resourceSpans": [{
      "resource": {"attributes": [{"key": "service.name", "value": {"stringValue": "test-service"}}]},
      "scopeSpans": [{
        "spans": [{
          "traceId": "aaaaaaaabbbbbbbbccccccccdddddddd",
          "spanId": "eeeeeeeeffffffff",
          "name": "test-span",
          "kind": 1,
          "startTimeUnixNano": "1000000",
          "endTimeUnixNano": "2000000"
        }]
      }]
    }]
  }'

# Then search for it in Grafana → Explore → Tempo:
# Service Name: test-service

# If app can't reach Tempo:
# The OTLP endpoint must be reachable from the app container
# For apps on the monitoring network:
OTEL_EXPORTER_OTLP_ENDPOINT=http://tempo:4318
# For apps on a different Docker network:
# Connect the app's network to the monitoring network:
docker network connect monitoring your-app-container

# Check Prometheus remote_write status:
curl -s http://localhost:9090/api/v1/status/config | jq '.data | contains("remote_write")'

# Check remote_write errors in Prometheus logs:
docker logs prometheus --tail 30 | grep -iE '(remote_write|failed|error)'

# Monitor remote_write queue health:
curl -s 'http://localhost:9090/metrics' | grep 'prometheus_remote_storage'
# Key metrics:
# prometheus_remote_storage_samples_pending — samples waiting to be sent
# prometheus_remote_storage_failed_samples_total — samples that failed
# prometheus_remote_storage_sent_bytes_total — bytes successfully sent

# If remote_write is lagging (pending > 10000):
# Increase remote_write queue capacity in prometheus.yml:
# remote_write:
#   - url: http://mimir:9009/api/v1/push
#     queue_config:
#       max_samples_per_send: 10000
#       max_shards: 10
#       capacity: 50000

# Verify Mimir is accepting the writes:
curl -s http://localhost:9009/api/v1/query?query=up | jq '.status'
# Should return: success if Prometheus data is in Mimir
