# Check MinIO version:
docker exec minio minio --version

# Verify mc CLI is configured:
mc alias list

# Check current cluster health:
mc admin info local

# Verify all drives are healthy:
mc admin health local

# Check disk usage:
mc admin disk local --json | jq '.disks[] | {path: .path, state: .state, used: .usedSpace}'

# docker-compose.distributed.yml
# 4-node MinIO cluster with 2 drives per node (8 drives total, EC:4)
# Deploy this on a single host for testing, or split across 4 servers for production

version: '3.8'

x-minio-common: &minio-common
  image: quay.io/minio/minio:latest
  command: server
    --console-address ":9001"
    http://minio{1...4}/data{1...2}
  environment:
    MINIO_ROOT_USER: ${MINIO_ROOT_USER}
    MINIO_ROOT_PASSWORD: ${MINIO_ROOT_PASSWORD}
    MINIO_VOLUMES: "/data1 /data2"  # 2 drives per node
    # Erasure coding stripe size — EC:4 requires minimum 4 drives
    MINIO_ERASURE_STRIPE_SIZE: 4
    # Site name for replication:
    MINIO_SITE_NAME: primary-site
    # Health check:
    MINIO_HEALTHCHECK_ENABLE: "on"
  expose:
    - "9000"
    - "9001"
  healthcheck:
    test: ["CMD", "curl", "-f", "http://localhost:9000/minio/health/live"]
    interval: 30s
    timeout: 20s
    retries: 3

services:
  minio1:
    <<: *minio-common
    hostname: minio1
    volumes:
      - minio1-data1:/data1
      - minio1-data2:/data2

  minio2:
    <<: *minio-common
    hostname: minio2
    volumes:
      - minio2-data1:/data1
      - minio2-data2:/data2

  minio3:
    <<: *minio-common
    hostname: minio3
    volumes:
      - minio3-data1:/data1
      - minio3-data2:/data2

  minio4:
    <<: *minio-common
    hostname: minio4
    volumes:
      - minio4-data1:/data1
      - minio4-data2:/data2

  # Nginx load balancer for distributed MinIO:
  nginx:
    image: nginx:alpine
    container_name: minio_lb
    volumes:
      - ./nginx-minio.conf:/etc/nginx/nginx.conf:ro
    ports:
      - "9000:9000"   # S3 API
      - "9001:9001"   # Console
    depends_on:
      - minio1
      - minio2
      - minio3
      - minio4

volumes:
  minio1-data1: minio1-data2:
  minio2-data1: minio2-data2:
  minio3-data1: minio3-data2:
  minio4-data1: minio4-data2:

# nginx-minio.conf
user nginx;
worker_processes auto;

events {
    worker_connections 1024;
}

http {
    upstream minio_s3 {
        least_conn;  # Route to least-loaded node
        server minio1:9000;
        server minio2:9000;
        server minio3:9000;
        server minio4:9000;
    }

    upstream minio_console {
        least_conn;
        server minio1:9001;
        server minio2:9001;
        server minio3:9001;
        server minio4:9001;
    }

    server {
        listen 9000;
        listen [::]:9000;

        # Disable buffering for large file uploads/downloads:
        client_max_body_size 0;
        proxy_buffering off;
        proxy_request_buffering off;

        location / {
            proxy_pass http://minio_s3;
            proxy_http_version 1.1;
            proxy_set_header Host $host:$server_port;
            proxy_set_header X-Real-IP $remote_addr;
            proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
            proxy_set_header X-Forwarded-Proto $scheme;
            proxy_connect_timeout 300s;
            proxy_send_timeout 300s;
            proxy_read_timeout 300s;
            chunked_transfer_encoding off;
        }
    }

    server {
        listen 9001;
        listen [::]:9001;

        location / {
            proxy_pass http://minio_console;
            proxy_http_version 1.1;
            proxy_set_header Upgrade $http_upgrade;
            proxy_set_header Connection "upgrade";
            proxy_set_header Host $host:$server_port;
        }
    }
}

# Start the cluster:
docker compose -f docker-compose.distributed.yml up -d

# Verify cluster formed correctly:
mc alias set distributed http://localhost:9000 ${MINIO_ROOT_USER} ${MINIO_ROOT_PASSWORD}
mc admin info distributed
# Look for: "Erasure Code: EC:4" and all 8 drives showing as "healing: false"

# Verify erasure coding is active:
mc admin info distributed | jq '.info.backend'
# Should show: {"Type": "Erasure", "OnlineDisks": 8, "OfflineDisks": 0}

# Upload a test object:
echo "erasure coding test" | mc pipe distributed/test-bucket/test-object.txt

# Simulate drive failure by stopping one node:
docker stop minio_minio4_1

# Verify object is still readable with one node down:
mc cat distributed/test-bucket/test-object.txt
# Should still output the content — erasure coding in action

# Check cluster health with degraded node:
mc admin info distributed | jq '.info.backend'
# OnlineDisks: 6, OfflineDisks: 2 — still operating, still reading

# Restore the failed node:
docker start minio_minio4_1

# MinIO automatically heals degraded objects when the node rejoins:
mc admin heal distributed --recursive --verbose
# Watch healing progress:
watch -n5 'mc admin info distributed | jq .info.backend'

# Prerequisites:
# - Site A: https://minio-site-a.yourdomain.com
# - Site B: https://minio-site-b.yourdomain.com
# - Both sites must use identical root credentials OR service accounts
# - Both sites must be empty (no existing buckets) before configuring replication
# - Both sites need the same MINIO_SITE_NAME set

# Step 1: Configure mc aliases for both sites:
mc alias set site-a https://minio-site-a.yourdomain.com ${SITE_A_ACCESS_KEY} ${SITE_A_SECRET_KEY}
mc alias set site-b https://minio-site-b.yourdomain.com ${SITE_B_ACCESS_KEY} ${SITE_B_SECRET_KEY}

# Step 2: Enable site replication (run from either site):
mc admin replicate add site-a site-b

# This configures active-active replication where:
# - Writes to site-a are replicated to site-b
# - Writes to site-b are replicated to site-a
# - Bucket creation/deletion, IAM policies, and object data all replicate

# Step 3: Verify replication is established:
mc admin replicate info site-a
# Should show: Replicated to site-b | Status: active

# Step 4: Test replication:
mc mb site-a/replicated-test
echo "site replication test" | mc pipe site-a/replicated-test/test.txt

# Check it appeared on site-b:
mc cat site-b/replicated-test/test.txt
# Should return the same content

# Step 5: Monitor replication lag:
mc admin replicate status site-a
# Shows: pending objects, failed objects, and lag in seconds

# For selective replication (specific buckets, not whole site),
# use bucket-level replication rules instead of site replication
# Useful when you only need to replicate critical data cross-region

# Step 1: Enable versioning on source bucket (required for replication):
mc version enable site-a/critical-assets

# Step 2: Create target bucket:
mc mb site-b/critical-assets-backup
mc version enable site-b/critical-assets-backup

# Step 3: Create replication policy on source:
mc replicate add site-a/critical-assets \
  --remote-bucket https://site-b-access-key:[email protected]/critical-assets-backup \
  --replicate delete-marker,delete,existing-objects

# Step 4: Verify replication rule:
mc replicate ls site-a/critical-assets

# Step 5: Check replication status per bucket:
mc replicate status site-a/critical-assets
# Shows: objects queued, completed, failed

# Trigger immediate sync of existing objects:
mc replicate resync start site-a/critical-assets
mc replicate resync status site-a/critical-assets
# Monitor until Complete status

# IMPORTANT: Object locking must be enabled at bucket creation
# It cannot be added to an existing bucket

# Create a compliance bucket with object locking:
mc mb --with-lock distributed/compliance-records

# Set default retention policy (GOVERNANCE or COMPLIANCE mode):
# GOVERNANCE: admins with special permissions can override
# COMPLIANCE: NO ONE can delete or modify until retention period expires

# Set COMPLIANCE mode retention (stricter — preferred for regulated industries):
mc retention set --default COMPLIANCE 7y distributed/compliance-records
# Now ALL objects in this bucket are retained for 7 years by default

# Verify retention policy:
mc retention info distributed/compliance-records

# Upload a compliance document:
mc cp /path/to/contract.pdf distributed/compliance-records/2026/Q1/contract.pdf

# Verify the object is locked:
mc stat distributed/compliance-records/2026/Q1/contract.pdf | grep -i retain
# Shows: Retention: COMPLIANCE | Retain Until: 2033-04-09

# Try to delete it (should fail):
mc rm distributed/compliance-records/2026/Q1/contract.pdf
# Error: object is WORM protected

# You can set per-object retention overrides:
mc retention set COMPLIANCE "2030-12-31T00:00:00Z" \
  distributed/compliance-records/2026/Q1/special-contract.pdf

# Versioning keeps previous versions of objects when they're overwritten or deleted
# Useful for user file storage, configuration backups, and any "undo" capability

# Enable versioning on a bucket:
mc version enable distributed/user-files

# Verify versioning is on:
mc version info distributed/user-files
# Returns: Versioning status: Enabled

# Upload a file, then overwrite it:
echo "version 1" | mc pipe distributed/user-files/document.txt
echo "version 2" | mc pipe distributed/user-files/document.txt
echo "version 3" | mc pipe distributed/user-files/document.txt

# List all versions:
mc ls --versions distributed/user-files/document.txt
# Shows 3 versions with different version IDs

# Restore a specific version:
VERSION_ID=$(mc ls --versions --json distributed/user-files/document.txt | \
  jq -r 'select(.versionId) | .versionId' | tail -3 | head -1)  # Second version

mc cp --version-id "$VERSION_ID" \
  distributed/user-files/document.txt \
  distributed/user-files/document-v2-restored.txt

# Delete a specific version (permanent):
mc rm --version-id "$VERSION_ID" distributed/user-files/document.txt

# Set versioning to SUSPENDED (keep existing versions, don't create new ones):
mc version suspend distributed/user-files

# MinIO lifecycle rules use the S3 ILM (Intelligent Lifecycle Management) format
# Create a JSON policy file:

cat > lifecycle-policy.json << 'EOF'
{
  "Rules": [
    {
      "ID": "expire-old-logs",
      "Status": "Enabled",
      "Filter": {
        "Prefix": "logs/"
      },
      "Expiration": {
        "Days": 90
      }
    },
    {
      "ID": "clean-incomplete-uploads",
      "Status": "Enabled",
      "Filter": {},
      "AbortIncompleteMultipartUpload": {
        "DaysAfterInitiation": 7
      }
    },
    {
      "ID": "expire-old-versions",
      "Status": "Enabled",
      "Filter": {},
      "NoncurrentVersionExpiration": {
        "NoncurrentDays": 30,
        "NewerNoncurrentVersions": 5
      }
    },
    {
      "ID": "transition-to-warm-storage",
      "Status": "Enabled",
      "Filter": {
        "Prefix": "archives/"
      },
      "Transition": {
        "Days": 30,
        "StorageClass": "WARM"
      }
    }
  ]
}
EOF

# Apply the lifecycle policy:
mc ilm import distributed/app-data < lifecycle-policy.json

# Verify the policy was applied:
mc ilm ls distributed/app-data

# Check which objects would be expired (dry run):
mc ilm tier stats distributed/app-data

# Create a warm storage tier (MinIO → MinIO tier for cost savings):
# This requires configuring a lower-cost storage backend:
mc ilm tier add minio distributed warm-tier \
  --endpoint https://minio-warm.yourdomain.com \
  --access-key ${WARM_ACCESS_KEY} \
  --secret-key ${WARM_SECRET_KEY} \
  --bucket warm-data \
  --prefix archive-tier/

# Objects in archives/ prefix will automatically move to warm tier after 30 days

# MinIO exposes Prometheus metrics natively
# Enable metrics collection:
mc admin prometheus generate distributed > minio-prometheus.yaml
cat minio-prometheus.yaml
# Outputs a scrape config with authentication tokens

# Add to prometheus.yml:
# - job_name: 'minio'
#   bearer_token: GENERATED_TOKEN
#   metrics_path: /minio/v2/metrics/cluster
#   scheme: https
#   static_configs:
#     - targets: ['minio.yourdomain.com:9000']

# Key MinIO metrics for dashboards:
# minio_cluster_disk_free_bytes    — available storage
# minio_cluster_disk_total_bytes   — total capacity
# minio_cluster_disk_healing_total — drives being healed
# minio_s3_requests_total          — request rate by type
# minio_s3_errors_total            — error rate
# minio_node_process_uptime_seconds — per-node uptime

# Useful PromQL for Grafana panels:
# Storage utilization %:
# (1 - (minio_cluster_disk_free_bytes / minio_cluster_disk_total_bytes)) * 100

# Request rate (last 5 min):
# rate(minio_s3_requests_total[5m])

# Error rate:
# rate(minio_s3_errors_total[5m]) / rate(minio_s3_requests_total[5m]) * 100

# Alert: storage > 85% full:
# minio_cluster_disk_free_bytes / minio_cluster_disk_total_bytes * 100 < 15

# Download the official MinIO Grafana dashboard:
# Dashboard ID: 13502 at grafana.com/grafana/dashboards/13502
# Import to Grafana → Dashboards → Import → Enter ID 13502

#!/usr/bin/env python3
# minio-capacity-planner.py
# Analyzes MinIO usage trends and projects when you'll need more capacity

import subprocess
import json
from datetime import datetime, timedelta

def run_mc(command: str) -> dict:
    result = subprocess.run(
        ['mc'] + command.split(),
        capture_output=True, text=True
    )
    try:
        return json.loads(result.stdout)
    except Exception:
        return {"output": result.stdout}

# Get cluster-wide disk stats:
cluster_info = run_mc('admin info distributed --json')

total_bytes = 0
free_bytes = 0
buckets = []

if 'info' in cluster_info:
    info = cluster_info['info']
    for disk in info.get('backend', {}).get('disks', []):
        total_bytes += disk.get('totalSpace', 0)
        free_bytes += disk.get('freeSpace', 0)

used_bytes = total_bytes - free_bytes
used_pct = (used_bytes / total_bytes * 100) if total_bytes > 0 else 0

# Get per-bucket usage:
bucket_sizes = {}
result = subprocess.run(['mc', 'du', '--recursive', '--depth=1', 'distributed/'],
                        capture_output=True, text=True)
for line in result.stdout.strip().split('\n'):
    parts = line.split('\t')
    if len(parts) == 2:
        size_str, path = parts
        bucket = path.strip('/')
        # Convert to bytes (mc returns human-readable)
        bucket_sizes[bucket] = size_str

print(f"MinIO Capacity Report — {datetime.now().strftime('%Y-%m-%d %H:%M')}")
print("=" * 60)
print(f"Total capacity: {total_bytes / 1e12:.1f} TB")
print(f"Used: {used_bytes / 1e12:.1f} TB ({used_pct:.1f}%)")
print(f"Free: {free_bytes / 1e12:.1f} TB")
print()
print("Top buckets by size:")
for bucket, size in sorted(bucket_sizes.items(), key=lambda x: x[1], reverse=True)[:10]:
    print(f"  {bucket:40} {size}")

# Warning thresholds:
if used_pct > 85:
    print(f"\n🚨 CRITICAL: Storage is {used_pct:.1f}% full — add capacity immediately")
elif used_pct > 70:
    print(f"\n⚠️  WARNING: Storage is {used_pct:.1f}% full — plan capacity expansion")
else:
    print(f"\n✅ Storage utilization is healthy at {used_pct:.1f}%")

# Schedule weekly:
# 0 9 * * 1 python3 /opt/scripts/minio-capacity-planner.py | mail -s "Weekly MinIO Capacity" [email protected]

# MinIO expands by adding server pools — new groups of servers
# Existing data doesn't need to move; new writes distribute across pools
# This is a zero-downtime horizontal expansion

# Current state: 4 nodes (minio1-4) with the original pool
# Adding a new pool: minio5-8 with additional drives

# Step 1: Prepare the new nodes:
# Install MinIO on minio5, minio6, minio7, minio8
# Mount dedicated drives at /data1 and /data2 on each

# Step 2: Update the MinIO command on ALL nodes to include the new pool:
# Old command:
# server http://minio{1...4}/data{1...2}

# New command (add the second pool after a space):
# server http://minio{1...4}/data{1...2} http://minio{5...8}/data{1...2}

# Update docker-compose.yml on all 8 nodes:
# command: server --console-address ":9001" \
#   http://minio{1...4}/data{1...2} \
#   http://minio{5...8}/data{1...2}

# Step 3: Rolling restart — restart one node at a time:
# MinIO continues serving requests during rolling restart
for i in 1 2 3 4 5 6 7 8; do
  docker restart minio${i}
  sleep 30  # Wait for node to rejoin before restarting next
  mc admin info distributed | jq '.info.backend.onlineDisks'
done

# Step 4: Verify new pool is active:
mc admin info distributed
# Should now show: 16 online disks (8 original + 8 new)
# New writes distribute across both pools automatically

# Step 5: Verify existing data is still accessible:
mc cat distributed/test-bucket/test-object.txt
# Existing data remains in original pool — no rebalancing needed

# MinIO distributed mode requires all nodes to start with the same configuration
# and be able to reach each other on port 9000

# Step 1: Test inter-node connectivity:
docker exec minio1 ping -c 3 minio2
docker exec minio1 curl -s http://minio2:9000/minio/health/live
# Should return: OK

# Step 2: Verify all nodes have identical configuration:
for node in minio1 minio2 minio3 minio4; do
  echo "=== $node ==="
  docker exec $node env | grep MINIO_ROOT_USER
done
# ROOT_USER must be IDENTICAL on all nodes
# If different, the cluster won't form

# Step 3: Check MinIO logs for specific errors:
docker logs minio1 --tail 30 | grep -iE '(error|failed|unable|warn)'

# Common issues:
# - Different MINIO_ROOT_PASSWORD on different nodes:
#   Fix: set identical credentials in .env and restart all nodes simultaneously

# - Drives not writable:
#   docker exec minio1 touch /data1/test
#   If permission denied: fix volume mount ownership
#   docker run --rm -v minio1-data1:/data alpine chown -R 1000:1000 /data

# - Insufficient drives for erasure coding:
#   MinIO requires minimum 4 drives for EC:2 or 8 for EC:4
#   With 8 drives across 4 nodes, you need 2 drives per node minimum

# Check replication backlog:
mc admin replicate status site-a | jq '.replication'

# If there's a large backlog:
# 1. Check network bandwidth between sites:
iperf3 -c minio-site-b.yourdomain.com -p 5201 -t 30
# Low bandwidth = slow replication

# 2. Check CPU load on both sites:
mc admin top distributed
# High CPU = slow replication processing

# 3. Manually trigger resync for stuck objects:
mc replicate resync start site-a/affected-bucket
mc replicate resync status site-a/affected-bucket

# 4. Check for failed replication objects:
mc replicate status site-a/affected-bucket --json | \
  jq '.stats | {pending: .pendingCount, failed: .failedCount}'

# 5. If replication is completely stuck (no progress in hours):
# Reset replication state on source:
mc admin replicate reset site-a site-b
# WARNING: This resets replication metadata — objects resync from scratch

# 6. Increase replication worker threads:
# Add to MinIO environment:
# MINIO_REPLICATION_WORKERS=100  # Default is 100
# MINIO_REPLICATION_FAILED_WORKERS=4  # Workers for failed object retry

# Check if an object is locked:
mc stat distributed/compliance-records/locked-file.pdf | grep -i retain
# Shows: Retain Until: 2030-12-31

# GOVERNANCE mode: admin can override the lock
# (Only works for GOVERNANCE, not COMPLIANCE mode)
mc rm --bypass-governance distributed/compliance-records/locked-file.pdf

# COMPLIANCE mode: NO override is possible — by design
# You cannot delete compliance-locked objects before the retention date
# This is intentional for regulatory compliance

# If you accidentally locked objects with wrong retention date in COMPLIANCE mode:
# There is no fix — you must wait for the retention period to expire
# This is why COMPLIANCE mode testing should always be done in a test bucket first

# Best practice for compliance bucket setup:
# 1. Test with GOVERNANCE mode first:
mc retention set --default GOVERNANCE 30d distributed/test-compliance-bucket
# 2. Verify everything works as expected
# 3. Create production COMPLIANCE bucket with correct retention period
# 4. Document the retention period and who approved it

# Check all locked objects in a bucket:
mc ls --recursive --json distributed/compliance-records/ | \
  jq 'select(.retainUntilDate != null) | {key: .key, retain_until: .retainUntilDate}'
